2025 Street motorcycle CM125-12

110cc / 120cc / 125cc

CM125-12

  • Engine Type: Single cylinder, four stroke, air cooled, horizontal
  • Dimensions (L×W×H): 1900×810×1100
  • Wheelbase (mm): 1210
  • Displacement (mL): 140
  • Starting method: Electric
  • Fuel tank capacity (L): 13L
  • Maximum speed: 93KW
  • Tire size (front/rear): 100/80-14 120/80-14/

（Standard Configuration Technical Parameters）
ITEMSCM125-12 CONTENTS
Vehicle
Parameters		VIN No. (The first 8 digits of VIN)LTEPBJC0#RA000001
Dimensions (L×W×H)（ mm）1900×810×1100
Wheelbase（ mm）1210
Minimum ground clearance（ mm）150
Seat height（ mm）720
Vehicle curb weight（kg）96
Rated load mass（kg）150
Brake type (front/rear)Disc / Drum
Brake operation method (front/rear)Hand operation/foot operation
Rim type (front/rear)Spoke/spoke
Tire size (front/rear)100/80-14 120/80-14/
Tire pressure (front/rear) (kPa)225/250
Maximum speed93
Starting performance (s)≤15

Accelerated performance (s)		start acceleration(s)≤16
Beyond Acceleration (s)≤15
Gradeability    ( ° )≥18
fuel tank capacity（L）13L
 Trademark/ ModelYX1P56FMJ/X150S
 TypeSingle   cylinder,  four  stroke,  air   cooled, horizontal
Vehicle
Parameters		Bore x Stroke（ mm）56×57
Displacement（ mL）140
Compression ratio8.8 ：1
Maximum    net    power    and   corresponding   speed     （ kW/6.8/7500（1±1.5%）
Maximum   torque   and   corresponding   speed     （ N    · m/9.7/5500（1±1.5%）
Minimum no-load stable speed (idle speed)（r/min）1500±150
Minimum fuel consumption（g/（kW · h））≤354
Fuel type and gradeGasoline 90# and above
Lubricant gradeSF 15W/40
Lubricant capacity（L）1.0L
Lubrication methodPressure, splash compound
Clutch typeManual wet multi-piece
Transmission type4 gears
Starting methodElectric
Ignition methodCDI
Shift method4 gears non-cyclic
Transfer methodChain drive
   4 gears Primary gear3.722
First gear3.273
Second gear1.938
Third gear1.350
Fourth gear1.043
Final gear3.214

Component
parameters		Carburetor Model or SpecificationPZ22（Nibbi）
Catalytic Converter Model or Specification
Spark plug model or specificationNGK DR8EA/TORCH-A7RTC
Battery model or specification12V/6.5AH maintenance-free battery
Air filter typeFoam filter
Exhaust muffler systemSingle
Radio disturbance suppression methodImpedance
Remark: Description of
vehicle status		front shock absorberHydraulic  spring  type,  non-adjustable,  total  length:  690mm,  45  steel,  matte-black, recovery  resistance  180N,  95mm  travel.  32mm  fork  tube  diameter,  outer  diameter 41mm
rear shock absorberAdjustable rear shock absorber with built-in airbag, 55mm travel. Installation center 310mm, 15-coil spring, 7mm diameter
carburetorPZ22  Nibi  large  diameter,  with  manual  plunger  adjustment  knob,  low-temperature starting    damper    handle,    chrome-plated    hardened    plunger,   wear-resistant, low resistance, faster oil return response.
handlebar22mm diameter handlebar, leather texture painting process
upper  connection
board		101A cast aluminum alloy, high strength, light weight, artistic
lower connection board35 steel forging lower connection board , high strength
forkSteel  square  pipe,  combined  welding,  more  flexible,  rear  shock  absorber  is  more comfortable
rear  brake pedalShrink tube technology
side standSteel round pipe
chain428H-104
footrest12mm diameter steel&rubber footrest
headlightLED round headlight, low light strips of daytime lights , lens LED of high and low light, high brightness up to 30000Cd, upper and lower separation, power: 12V20W/ 10W
rear lightLED taillight with LED high light brake warning light. Power: 12V5W/3W
turn signalsLED turn signal, power: 12V/1.5W
instrument assemblyDouble  round  LCD  instrument,  night  driving  is  not  dazzling,  strong  light  is  clear, five functions: HD, waterproof, shock-proof, anti-fog, anti-EMC interference
sprocket wheel428-38T- Galvanized
seat cushionFrosted leather, 8mm thick sponge
Remark:
Description of
vehicle status		mufflerStainless steel material, with protective cover, solid welding, beautiful, light weight, rust proof
brake systemFront disc/rear drum,  brake disc diameter  180mm,  rear drum diameter  130mm,  heat dissipation is faster and the braking effect is more sensitive.
aluminum wheel2.75X14 and 3.0X14, vacuum tire
tiresFront 100/80-17, rear 120/80-17, vacuum tire
frameTube sheet welding, High strength, double paint, electrocoating + leather grain
fuel tank13L, long distance driving
  (selling points)This is CP150-12  with 150cc horizontal engine, optimized and improved based on the original CP150-12,
1.  The aluminum wheel is changed from the original 12 inch to 14 inch, so it looks like more practical.
2.  All lights changed to the LED state, the strong light of the LED instrument makes the 3 Instrument data display clearer and does not glare at night.
3.  Adjustable rear shock absorber with built-in airbag is more comfortable.
4.  The corrosion resistance of stainless steel mufflers is enhanced.
5.  The seat cushion is more comfortable and beautiful.
6.  This  motorcycle  has  reliable  performance,  strong  power, flexible gear  shifting  and simple maintenance.
7.  The  seat  height  is  750mm,  suitable  for  all  drivers  (height  1.5m–1.9m),  ground clearance 150mm, it can easily overcome ordinary obstacles.
8.  The appearance of leisure,and Retro style characteristics.
9.  13L big fuel tank guarantee the long distance driving, large battery capacity ensures startup.
10.  The front disc rear drum ensures braking safety, vacuum tires avoid the risk of tire burst in high-speed driving.
11.  Excellent rear tire width-to-narrow ratio, fast bending without side slip.
