Engine |
Type: | 1 Cylinder, 4 stroke, air cooling |
Displacement: | 106.7cm3 |
Bore x Stroke: | 52.4mm x 49.5mm |
Compression Ratio: | (9.1 ± 0.1) : 1 |
Max. power (kw/r/min): | 4.8kW/7500±200min-1 |
Max. Torque (N.m/r/min): | 7.0N.m/6000±150min-1 |
Clutch Type: | Manual clutch |
Ignition: | C.D.I |
Starter system: | Electric/kick |
Transmission System: | Chain drive |
Chassis |
Brake system (front / rear): | Drum/drum |
Max. speed (km/h): | ≥85 |
Tire (front / rear): | 2.50-17 / 2.75-17 |
Fuel tank capacity (L): | 9L |
Fuel consumption (L/100km): | ≤1.8 |
Dimensions |
LxWxH (mm): | 1900mm x 760mm x 1110mm |
Seat height (mm): | 740mm |
Wheel base (mm): | 1210mm |
Ground clearance (mm): | 140mm |
Max. loading capacity (kgs): | 150kg |
Dry weight (kgs): | 85kg |
Continer loading |
Packing Size(mm): | 1560mm × 330mm × 820mm |
Container Loading(CBU): | 156 pcs/40HQ(CBU) |
Optional items |
Engine displacement: | 120cc |
Motorcycle Color: | Red, Black, Blue, Silverg, Ray, Dark Red, White |
