Engine Type
Yinxiang X150/1P56FMJSingle cylinder, four stroke, air-cooled/oil-cooled, horizontal
Transmission type
Constant mesh two-stage transmission with four speeds
Dimensions (L×W×H)
1820mm * 800mm * 1100mm
Fuel tank capacity（L)
6L
Tire size (front/rear)
70/100-17 / 90/100-14
Vehicle curb weight
80 (kg)
Custom Your Motorcycle
ODM/OEM Suport
CHAMP is a top motorcycle manufacturer in China. With over 20 years of experience in motorcycle manufacturing and global export, CHAMP operates 2 advanced factories and serves over 80 countries worldwide. We provide wholesale and custom services to meet the specific needs of different markets.
Custom Your Motorcycle
Top Off-road Motorcycle
Professional off-road, easy to control: high-strength frame, professional off-road tires, and long-travel shock absorption system can easily cope with various road conditions, allowing you to enjoy the fun of off-road!
Looking for global distributor
Our motorcycles use high-quality parts and advanced manufacturing technology to ensure that each vehicle has excellent performance and reliable quality, allowing consumers to buy with confidence.We provide a full range of market support, including advertising, promotional activity planning, product training, etc., to help you quickly open up the market and improve sales performance.
Choose us, worry-free after-sales
Our after-sales team is composed of senior factory technicians who have participated in the design and production of each motorcycle and are familiar with the vehicle structure and performance. Whether it is a complex circuit failure or a difficult mechanical problem, they can accurately diagnose and quickly repair it.
Product Detailes
Specification
| ENGINE | Engine Type | Yinxiang brand, 1 cylinder, four-stroke, Air/oil-cooled, overhead cam, inclined (horizontal 10°) |
| Displacement | 140.4cm3 | |
| Bore x Stroke | 56mm × 57mm | |
| Compression Ratio | 8.6:1 | |
| Ignition Method | CDI | |
| Starting Mode | Electric/Kick | |
| Transmission | International four gears | |
| Max.Power(Kw/Rpm) | 6.8/7500 (1±1.5%) | |
| Max.Torque(Nm/Rpm) | 9.7/5500（1±1.5%） | |
| BODY | Length x Width x Height | 1820*800*1100mm |
| Min. Ground Clearance | 280mm | |
| Wheelbase | 1210mm | |
| Seat Height | 810mm | |
| Net Weight | 80kg | |
| Max.Loading | 150kg | |
| Fuel Tank Capacity | 6L | |
| PERFORMANCE | Eco fuel consumption(L/100km) | 2.4L |
| Max.Speed | 85 km/h | |
| OTHERS | Wheel type | Spoke/Spoke |
| Front/Rear.Tire | 70/100-17/90/100-14 | |
| Brake (Front) | Disc brake | |
| Brake (Rear) | Disc brake | |
| Battery | 12V/2Ah (gel battery) | |
| Packing Size | 1370mm × 460mm × 770mm | |
| Loading Quantity (40HQ) | 126 pcs/40HQ | |
| Loading Quantity (20GP) | 40pcs / 20GP |
